How To Use Tinkercad Vol 2

Master the basics of servo motor control with Arduino UNO. This short and practical tutorial will walk you through circuit ... Show more
Video preview
Instructor
Aniq Qusyairi
3 Students enrolled
0
0 reviews
Course details
Duration : 1 Hours
Lectures : 2
Quizzes : 1
Level : Beginner
  • Description
  • FAQ
  • Reviews
  • Grade

In this course,. you will explore how to control a servo motor using an Arduino UNO.Through a step-by-step guide, students will learn how to connect the servo ,otor, write Arduino code using the Servo.h library and observe the servo’s motion from 0° to 180°. This hands on project is perfect for beginners looking to build a strong foundation in motor control and basic robotics.

What is a servo motor and how is it different from a regular motor?
A servo motor is a motor that can precisely control angular position. Unlike regular DC motors, it can rotate to a specific angle such as 0°, 90° or 180° based on the signal it receives.
Which pin should I connect the servo motor to on the Arduino?
In this project, the servo motor's signal wire is connected to digital pin 9 on the Arduino UNO. You can change this in code if needed.
Do I need separate power source for the servo motor?
For small servo motors like the SG90, the Arduino's 5V output is usually enough. However, for larger on multiple servo, it's recommended to use an external power supply.
Why is my servo motor jittering or not moving properly?
This can happen due to the insufficient power, loose wiring, missing or incorrect use of the Servo.h library or wrong signal pin assignment in code.
Can i control more than one servo with Arduino UNO?
Yes. You can control up to 12 servo motors on most Arduino boards, but be mindful of power limitations.
What is maximum rotation angle of a servo motor?
Most standard servo motors rotate between 0° to 180°. Some special models may support 270° or continuous rotattion
Can I use a breadboard for this project?
Yes, using a breadboard makes it easier to manage your connections cleanly and securely, especially for beginners.
Grade details
Course:
Student:
Enrollment date:
Course completion date:
Grade:
Grade Points
Grade Range
Regenerate Grades
Exams:
Sign in to account to see your Grade
Sign In
Basic info

Project title: Arduino UNO Tutorial - Servo Motor Project (Set Up)
Level: Beginner
Software: Arduino IDE, Tinkercad
Hardware Components:
- Arduino UNO board
- SG90 (or compatible) servo motor
- Jumper wires
- USB cable
- Breadboard

Course requirements
  • Basic understanding of computer operation.
  • Arduino UNO board and USB cable.
  • Installed Arduino IDE on your computer.
  • Basic knowledge of how to use jumper wires and breadboard.
  • Interest in electronics or robotics.
Intended audience
  • Students that want to starting with Arduino.
  • STEM teachers looking for beginner friendly Arduino projects.
  • Parents and kids exploring electronics together.
  • Anyone curious about robotics and automation.
